KEYBOARD
Right: 52. Left: 120 Basses. Left and Right separate velocity range controls. 6 Velocity curves. Pitch & Modulation joystick. Aftertouch.
DISPLAY
Lcd color Tft 7. Touch Screen capacitive 800×480 dots. Brightness control.
PLAYER
Files recognized: Wav, Midi, Mp3, Mp4, Avi, Mov, flv, Cdg, Jpg, Txt, Pdf. Functions: Marker. Sync/Next. Autoplay. Lead Mute. GM part. Lyric Off. Cross fade. File Search. Play List. My Folder. Transposer. Time stretching. Metronome Click. Midi Multimix. Song Drum Restyle.
DJ
Double Audio and Midi player with Tempo & Pitch stretching, Pfl, Sync, Tap tempo, Cue, Fx Pad, Backspin, Brake.
JUKE BOX
Playlist, My Folders, SFX Special Effects.
PIC & MOVIE
Jpg & Mp4, Avi, Mov, Flv, Karaoke background, Movie/PDF to RGB, Pic List, Autoshow.
DVI
Video Monitor Out, Karaoke Lyric/Mirror.
MENU
Disk, Midi, Play Modes, Audio Edit, Language, Footswitch, Preferences, Controls, Video, Reg. Set up, Arabic Mode, Micro/Vocal, Mic2/Guitar, juke box, DSP, records.
MEDIA
Internal Storage: SSD Card 16G. Usb: 3 Host+1 device. External storage: Removable SATA 2/3 2.5 HD
SOUNDBOARD
543 GM Sounds, 4 sound banks, voice list, 48 drum sets + stereo special kit, live drum modeling.
VOICES
368 preset voices, new stereo grand piano, 368 user voice, 2nd voice, V-tone, double up/down, harmony, EFX instert, voice editing.
ARRANGER
260 Styles full Audio Drum and Groove equipped. User Style section. Midi Drum Mixer & Remap. 4 Arranger ABCD. 4 Fill. 4 Break. 3 Intro. 3 Ending. Drum, Groove, Bass, Chords 1-5. Lower 1-2. Auto Fill. Fill to Arrange. To End. Reintro. Key Start. Key Stop. Restart. Count In. Drum Boost. 4 Voice Set. Voice to ABCD. VOice & Vari. 5 User Tabs. V-Tone.
ARRANGER MODES
Pianist (Auto-standard), bassist (Easy, expert), manual bass, bass to lowest.
STYLE MODELING
Interactive Modeling Library with massive audio drums, latin groove, Bass, Piano, Guitar and Orchestral templates.
PLAY MODES
Master Keyboard. Accordion Style and Classic. Guitar mode with Efx (thru Input). Organ with pedalboard.
REGISTRATIONS
4 Banks x 1024 Regs. Full Panel and function programming.
DSP
Type: Chorus, Reverb, Flanger, Phaser, Tremolo, Rotary, Echo Delay, Tap Delay, Equalizer, Distorsion, Amp simulator, Compressor, Filter. EFX Insert (54 types), 10 programmable Chains.
LIVE FX CONTROL
Decay, Release, Filter and Resonance slider control applied to Player, Drum, Bass & Chords. Low_Hi Eq to Player.
RECORDING
HD Recording: 1 stereo track. Loop. Audio edit with cut, normalize. Midi recording with phrase and song.
MICRO
XLR Input. Gain Control. Volume. Reverb. Micro On/Off Edit. Talk.
VOICETRON
3 Voice vocalizer. 10 Voicetron presets. 10 Voicetron User.
MIDI
In 1 (Gm), In 2 (Keyb). Out. Thru. Midi Set up: Standard, Computer & Sequencer, Keyboard Right, Accordion, Player, Style.
OUTPUT
Left/Right Stereo, Volume Pedal, Micro Out.
INPUT
Guitar (Instrument) /Micro2.
HEADPHONE
Stereo Headphone. Aux separate Out Assign (to Drums, Right, Bass, Click).
OPTIONAL
Footswitch 6 or 13, Volume Pedal, Sustain pedal, Hard Case, Bag.
AMPLIFIER & SUPPLY
2×20 watts. 2x Midrange speakers + 2x Tweeters. Speaker On/Off. External 15V.
DIMENSIONS
115x39x12’5cm. (46×15’6×5 inches)
WEIGHT
15 Kg. (33 Ibs)
