KEYBOARD
61 key light weighted. 3 Velocity Curves . Aftertouch. Portamento.Joystick: Pitch.Modulation. Transposer: +/- 24. Octave : +/- 2.
POLYPHONY
128 note. Multitimbral 48 parts
DISPLAY
Lcd color Tft 7”. Touch sensitive 800 x 480 dots. Brightness control.
PLAYER
Double Player. Files recognized : Wav, Midi , Mp3, Mp4, Avi, Mov, Flv, Cdg, Jpg, Txt, Pdf.
PLAYER FUNCTIONS
Marker. Sync/Next. Autoplay. Lead Mute. GM part. Lyric Off. Cross fade. File Search. Play List. My Folder. Transposer. Time stretching. Metronome Click. Midi Multimix. Song Drum Restyle. Audio and Midi synchronize.
AUDIO MULTITRACK PLAYER
5+1 Audio tracks with separate slider control
DJ
Double Audio and Midi player with Tempo & Pitch stretching, Pfl, Sync, Tap tempo, Cue, Fx Pad, Backspin, Brake.
JUKE BOX
Play List, My Folders, SFX Special Effects.
PIC & MOVIE
Jpg & Mp4, Avi, Mov, Flv, Karaoke background, Movie/PDF To RGB, Pic List, Autoshow.
DVI
Video Monitor Out, Karaoke Lyric / Mirror.
MENU
Disk, Midi , Play Modes, Audio Edit, Language, Footswitch, Preferences, Controls, Video, Reg. Set up, Arabic Mode.
MEDIA
Internal Storage: SSD Card 16G. External Storage: Removable SATA 2/3 2.5 HD. USB: 3 Host + 1 device.
SOUNDBOARD
543 GM Sounds. 4 Sound Banks. Voice List. 48 Drum Sets + Stereo Special Kit. Live Drum Modeling.
VOICES
368 Preset Voices. New Stereo Grand Piano. 368 User Voice. 2nd Voice. V-Tone. Double Up / Down. Harmony. EFX Insert. Voice Editing.
RAM SOUNDS
46 voices ( instant loading). Hi-quality tonewheel Organ and Orchestral sounds.
ARRANGER
260 Styles full Audio Drum and Groove equipped. User Style section. Midi Drum Mixer & Remap. 4 Arranger ABCD. 4 Fill. 4 Break. 3 Intro. 3 Ending.
Drum, Groove, Bass, Chords 1-5. Lower 1-2.Auto Fill. Fill to Arrange. To End. Reintro. Key Start. Key Stop. Restart. Count In. Drum Boost. 4 Voice Set. Voice to ABCD. Voice & Vari. 5 User Tabs. V-Tone.
ARRANGER MODES
Pianist ( Auto- Standard ). Bassist ( Easy_Expert ). Manual Bass. Bass to Lowest.
STYLE MODELING
Interactive Modeling Library with massive Audio Drums, Bass, Latin Groove, Piano, Guitar and Orchestral templates.
PLAY MODES
Master keyboard. Accordion Style. Accordion Classic. Organ with Pedalboard. Guitar mode with Efx ( thru Input).
REGISTRATIONS
4 Bank x 1024 Regs. Full Panel and function programming.
DSP
Type : Chorus, Reverb, Flanger, Phaser, Tremolo, Rotary, Echo Delay, Tap Delay, Equalizer, Distorsion, Amp simulator, Compressor, Filter. EFX Insert (54 types). 10 programmable Insert Chains.
LIVE FX CONTROL
Decay, Release, Filter and Resonance slider control applied to Player, Drum, Bass & Chords. Low_Hi Eq to Player.
RECORDING
HD Recording : 1 Stereo track. Loop. Audio Edit with Cut, Normalize. Midi Recording. Phrase and Song.
MICRO
XLR Input. Gain control. Volume. Reverb. Micro On/Off Edit. Talk.
VOICETRON
3 Voice Vocalizer. 10 Voicetron Presets + 10 User.
INSTRUCTION MANUAL
Html on board.
MIDI
In1 ( Gm ), In 2 ( Keyb ). Out. Thru. Midi Set up : Standard, Computer & Sequencer, Keyboard Right, Accordion, Player , Style.
OUTPUT
Left/Right Stereo, Pedal Volume, Sustain Pedal, Micro Out.
INPUT
Guitar ( Instrument ) / Micro2 .
HEADPHONE
Stereo Headphone. Aux separate Out Assign ( to Drums, Right, Bass, Click).
OPTIONAL
Footswitch 6 or 13, Volume Pedal, Sustain pedal, Bag.
POWER SUPPLY
External 15 V.
AMPLIFIER
2 x 20 watts. 2 x Midrange speakers + 2 x Tweeters. Speaker On /Off.
DIMENSIONS
115 x 39 x 12,5 cm (46 x 15.6 x 5 inches).
WEIGHT
15 Kg (33 lbs).
